Surface Downlights

Surface Downlights

Useful and practical surface downlights with a broad range of outputs from 1,100 to 6,000 lumens.

Fully integrated control gear and replaceable RIDI LED modules or boards.



Looks Great in
Other Colours

Our standard White, Silver and Black is available on request, or any RAL is possible too.



Three Sizes

ADLR 195

195mm
1,100 2,000 or 3,000lm
White, Narrow or Broad distribution reflectors

ADLR 235

235mm
2,000 3,000 or 4,000lm
White, Narrow or Broad distribution reflectors

ADLR 410

∅410mm
5,000 or 5,000lm
Diamond Prism, Diamond Prism + Opal, Opal or Microprism diffusers

Three Reflectors

For 195mm and 235mm

W Reflector

High reflectivity white reflector with a wide distribution. Works well with additional diffusers or optics.

SMT Reflector

Satin Matt Aluminium reflector with narrow distribution and low glare even without additional optics or diffusers.

SMB Reflector

Satin Matt Aluminium reflector with broad distribution and low glare even without additional optics or diffusers.

Four Diffusers

For 410mm

DPO Diffuser

Diamond Prismatic panel for low glare with additional opal element to prevent imaging of the LEDs

DPS Diffuser

Diamond prismatic diffuser low glare.  LEDs appear as individual points of light.

MPS Diffuser

Laser etched circular prisms for extreme low glare in all directions.  LEDs appear as circles of light.

OS Diffuser

Opal panel provides bright, even illumination of the diffuser.  No visible LEDs.

Loads of Accessories

DR … DR-K
Decorative Rings

Silver, Grey, White or Gold

DR … SK
Clear Glass

195 & 235

DR ..
Frosted Glass

195 & 235

DR … SO
Opal Glass

195 & 235

DR … HO
Drop Diffuser

195 & 235

DR … SPM
Matt Centre Glass

195 & 235

ZSP
Wire Suspension

∅195 ∅235 & 410

DR … HWNR
Signage

195 & 235

Technical Information

ADLR 195

Optical Distribution:
White Reflector – W
Satin Matt Silver Reflector Broad Distribution – SMB
Satin Matt Silver Reflector Narrow Distribution – SMT
Output (lm):
1163 – 2957 lm
Control:
DALI – DA
Non-Dimming – ND

Colour Temperatures:
3,000K 4,000K
Colour:
White
IP Rating:
IP20

Specific Product Information and Downloads

Downloads - W Reflector
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
ADLR 195/1100-830 W / 0321866 194 mm 195 mm 830 1163 lm 8 W PDF LDT IMG
ADLR 195/1100-830 W-DALI / 0331866 194 mm 195 mm 830 1163 lm 8 W PDF LDT IMG
ADLR 195/1100-840 W / 0321870 194 mm 195 mm 840 1163 lm 8 W PDF LDT IMG
ADLR 195/1100-840 W-DALI / 0331870 194 mm 195 mm 840 1163 lm 8 W PDF LDT IMG
ADLR 195/2000-830 W / 0321867 194 mm 195 mm 830 2066 lm 16 W PDF LDT IMG
ADLR 195/2000-830 W-DALI / 0331867 194 mm 195 mm 830 2066 lm 16 W PDF LDT IMG
ADLR 195/2000-840 W / 0321871 194 mm 195 mm 840 2066 lm 16 W PDF LDT IMG
ADLR 195/2000-840 W-DALI / 0331871 194 mm 195 mm 840 2066 lm 16 W PDF LDT IMG
ADLR 195/3000-830 W / 0322027 194 mm 195 mm 830 3247 lm 23 W PDF LDT IMG
ADLR 195/3000-830 W-DALI / 0332027 194 mm 195 mm 830 3247 lm 23 W PDF LDT IMG
ADLR 195/3000-840 W / 0322030 194 mm 195 mm 840 3247 lm 23 W PDF LDT IMG
ADLR 195/3000-840 W-DALI / 0332030 194 mm 195 mm 840 3247 lm 23 W PDF LDT IMG
Downloads - SMB Reflector
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
ADLR 195/1100-830 SMB / 0321915 194 mm 195 mm 830 1067 lm 8 W PDF LDT IMG
ADLR 195/1100-830 SMB-DALI / 0331915 194 mm 195 mm 830 1067 lm 8 W PDF LDT IMG
ADLR 195/1100-840 SMB / 0321916 194 mm 195 mm 840 1067 lm 8 W PDF LDT IMG
ADLR 195/1100-840 SMB-DALI / 0331916 194 mm 195 mm 840 1067 lm 8 W PDF LDT IMG
ADLR 195/2000-830 SMB / 0321917 194 mm 195 mm 830 1926 lm 16 W PDF LDT IMG
ADLR 195/2000-830 SMB-DALI / 0331917 194 mm 195 mm 830 1926 lm 16 W PDF LDT IMG
ADLR 195/2000-840 SMB / 0321918 194 mm 195 mm 840 1926 lm 16 W PDF LDT IMG
ADLR 195/2000-840 SMB-DALI / 0331918 194 mm 195 mm 840 1926 lm 16 W PDF LDT IMG
ADLR 195/3000-830 SMB / 0322025 194 mm 195 mm 830 3010 lm 23 W PDF LDT IMG
ADLR 195/3000-830 SMB-DALI / 0332025 194 mm 195 mm 830 3010 lm 23 W PDF LDT IMG
ADLR 195/3000-840 SMB / 0322028 194 mm 195 mm 840 3010 lm 23 W PDF LDT IMG
ADLR 195/3000-840 SMB-DALI / 0332028 194 mm 195 mm 840 3010 lm 23 W PDF LDT IMG
Downloads - SMT Reflector
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
ADLR 195/1100-830 SMT / 0321923 194 mm 195 mm 830 1058 lm 8 W PDF LDT IMG
ADLR 195/1100-830 SMT-DALI / 0331923 194 mm 195 mm 830 1058 lm 8 W PDF LDT IMG
ADLR 195/1100-840 SMT / 0321924 194 mm 195 mm 840 1058 lm 8 W PDF LDT IMG
ADLR 195/1100-840 SMT-DALI / 0331924 194 mm 195 mm 840 1058 lm 8 W PDF LDT IMG
ADLR 195/2000-830 SMT / 0321925 194 mm 195 mm 830 1890 lm 16 W PDF LDT IMG
ADLR 195/2000-830 SMT-DALI / 0331925 194 mm 195 mm 830 1890 lm 16 W PDF LDT IMG
ADLR 195/2000-840 SMT / 0321926 194 mm 195 mm 840 1890 lm 16 W PDF LDT IMG
ADLR 195/2000-840 SMT-DALI / 0331926 194 mm 195 mm 840 1890 lm 16 W PDF LDT IMG
ADLR 195/3000-830 SMT / 0322026 194 mm 195 mm 830 2957 lm 23 W PDF LDT IMG
ADLR 195/3000-830 SMT-DALI / 0332026 194 mm 195 mm 830 2957 lm 23 W PDF LDT IMG
ADLR 195/3000-840 SMT / 0322029 194 mm 195 mm 840 2957 lm 23 W PDF LDT IMG
ADLR 195/3000-840 SMT-DALI / 0332029 194 mm 195 mm 840 2957 lm 23 W PDF LDT IMG

ADLR 235

Optical Distribution:
White Reflector – W
Satin Matt Silver Reflector Broad Distribution – SMB
Satin Matt Silver Reflector Narrow Distribution – SMT
Output (lm):
2071 – 3706 lm
Control:
DALI – DA
Non-Dimming – ND

Colour Temperatures:
3,000K 4,000K
Colour:
White
IP Rating:
IP20

Specific Product Information and Downloads

Downloads - W Reflector
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
ADLR 235/2000-830 W / 0321868 228 mm 235 mm 830 2071 lm 16 W PDF LDT IMG
ADLR 235/2000-830 W-DALI / 0331868 228 mm 235 mm 830 2071 lm 16 W PDF LDT IMG
ADLR 235/2000-840 W / 0321872 228 mm 235 mm 840 2071 lm 16 W PDF LDT IMG
ADLR 235/2000-840 W-DALI / 0331872 228 mm 235 mm 840 2071 lm 16 W PDF LDT IMG
ADLR 235/3000-830 W / 0321869 228 mm 235 mm 830 3260 lm 23 W PDF LDT IMG
ADLR 235/3000-830 W-DALI / 0331869 228 mm 235 mm 830 3260 lm 23 W PDF LDT IMG
ADLR 235/3000-840 W / 0321873 228 mm 235 mm 840 3260 lm 23 W PDF LDT IMG
ADLR 235/3000-840 W-DALI / 0331873 228 mm 235 mm 840 3260 lm 23 W PDF LDT IMG
ADLR 235/4000-830 W / 0322033 228 mm 235 mm 830 4046 lm 31 W PDF LDT IMG
ADLR 235/4000-830 W-DALI / 0332033 228 mm 235 mm 830 4046 lm 31 W PDF LDT IMG
ADLR 235/4000-840 W / 0322036 228 mm 235 mm 840 4046 lm 31 W PDF LDT IMG
ADLR 235/4000-840 W-DALI / 0332036 228 mm 235 mm 840 4046 lm 31 W PDF LDT IMG
Downloads - SMB Reflector
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
ADLR 235/2000-830 SMT / 0321927 228 mm 235 mm 830 1835 lm 16 W PDF LDT IMG
ADLR 235/2000-830 SMT-DALI / 0331927 228 mm 235 mm 830 1835 lm 16 W PDF LDT IMG
ADLR 235/2000-840 SMT / 0321928 228 mm 235 mm 840 1835 lm 16 W PDF LDT IMG
ADLR 235/2000-840 SMT-DALI / 0331928 228 mm 235 mm 840 1835 lm 16 W PDF LDT IMG
ADLR 235/3000-830 SMT / 0321929 228 mm 235 mm 830 2930 lm 23 W PDF LDT IMG
ADLR 235/3000-830 SMT-DALI / 0331929 228 mm 235 mm 830 2930 lm 23 W PDF LDT IMG
ADLR 235/3000-840 SMT / 0321930 228 mm 235 mm 840 2930 lm 23 W PDF LDT IMG
ADLR 235/3000-840 SMT-DALI / 0331930 228 mm 235 mm 840 2930 lm 23 W PDF LDT IMG
ADLR 235/4000-830 SMT / 0322032 228 mm 235 mm 830 3562 lm 31 W PDF LDT IMG
ADLR 235/4000-830 SMT-DALI / 0332032 228 mm 235 mm 830 3562 lm 31 W PDF LDT IMG
ADLR 235/4000-840 SMT / 0322035 228 mm 235 mm 840 3562 lm 31 W PDF LDT IMG
ADLR 235/4000-840 SMT-DALI / 0332035 228 mm 235 mm 840 3562 lm 31 W PDF LDT IMG
Downloads - SMT Reflector
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
ADLR 235/2000-830 SMB / 0321919 228 mm 235 mm 830 1880 lm 16 W PDF LDT IMG
ADLR 235/2000-830 SMB-DALI / 0331919 228 mm 235 mm 830 1880 lm 16 W PDF LDT IMG
ADLR 235/2000-840 SMB / 0321920 228 mm 235 mm 840 1880 lm 16 W PDF LDT IMG
ADLR 235/2000-840 SMB-DALI / 0331920 228 mm 235 mm 840 1880 lm 16 W PDF LDT IMG
ADLR 235/3000-830 SMB / 0321921 228 mm 235 mm 830 2934 lm 23 W PDF LDT IMG
ADLR 235/3000-830 SMB-DALI / 0331921 228 mm 235 mm 830 2934 lm 23 W PDF LDT IMG
ADLR 235/3000-840 SMB / 0321922 228 mm 235 mm 840 2934 lm 23 W PDF LDT IMG
ADLR 235/3000-840 SMB-DALI / 0331922 228 mm 235 mm 840 2934 lm 23 W PDF LDT IMG
ADLR 235/4000-830 SMB / 0322031 228 mm 235 mm 830 3706 lm 31 W PDF LDT IMG
ADLR 235/4000-830 SMB-DALI / 0332031 228 mm 235 mm 830 3706 lm 31 W PDF LDT IMG
ADLR 235/4000-840 SMB / 0322034 228 mm 235 mm 840 3706 lm 31 W PDF LDT IMG
ADLR 235/4000-840 SMB-DALI / 0332034 228 mm 235 mm 840 3706 lm 31 W PDF LDT IMG

ADLR 410

Optical Distribution:
Miscroprism and Opal – DPO
Diamond Microprism – DPS
Conical Miscroprism  – MPS
Opal  – OS
Output (lm):
3900 – 5280 lm
Control:
DALI – DA
Non-Dimming – ND

Colour Temperatures:
3,000K 4,000K
Colour:
White
IP Rating:
IP20

Specific Product Information and Downloads

Downloads - DPO Optic
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
ADLR 410/5000-840 DPS / 0321243 68 mm 410mm 840 4390 lm 30 W PDF LDT IMG
ADLR 410/5000-840 DPS-DALI / 0331243 68 mm 410mm 840 4390 lm 30 W PDF LDT IMG
ADLR 410/6000-840 DPS / 0321247 68 mm 410mm 840 5280 lm 37 W PDF LDT IMG
ADLR 410/6000-840 DPS-DALI / 0331247 68 mm 410mm 840 5280 lm 37 W PDF LDT IMG
Downloads - DPS Optic
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
ADLR 410/5000-840 DPO / 0321242 68 mm 410mm 840 3900 lm 30 W PDF LDT IMG
ADLR 410/5000-840 DPO-DALI / 0331242 68 mm 410mm 840 3900 lm 30 W PDF LDT IMG
ADLR 410/6000-840 DPO / 0321246 68 mm 410mm 840 4710 lm 37 W PDF LDT IMG
ADLR 410/6000-840 DPO-DALI / 0331246 68 mm 410mm 840 4710 lm 37 W PDF LDT IMG
Downloads - MPS Optic
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
ADLR 410/5000-840 MPS / 0321244 68 mm 410mm 840 3550 lm 30 W PDF LDT IMG
ADLR 410/5000-840 MPS-DALI / 0331244 68 mm 410mm 840 3550 lm 30 W PDF LDT IMG
ADLR 410/6000-840 MPS / 0321248 68 mm 410mm 840 4270 lm 37 W PDF LDT IMG
ADLR 410/6000-840 MPS-DALI / 0331248 68 mm 410mm 840 4270 lm 37 W PDF LDT IMG
Downloads - OS Optic
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
ADLR 410/5000-840 OS / 0321241 68 mm 410mm 840 4090 lm 30 W PDF LDT IMG
ADLR 410/5000-840 OS-DALI / 0331241 68 mm 410mm 840 4090 lm 30 W PDF LDT IMG
ADLR 410/6000-840 OS / 0321245 68 mm 410mm 840 4930 lm 37 W PDF LDT IMG
ADLR 410/6000-840 OS-DALI / 0331245 68 mm 410mm 840 4930 lm 37 W PDF LDT IMG
