ROBUST

Compact Power Pack

Keeps its promise

Robust does what it promises. Die cast aluminium housing covered with toughened safety glass.

Ball impact resistant to DIN 18032, part 3

Power!!!

Up to 30,000 Lumens

4,000K or 6,500K

Wide or Narrow Beam

Product Selection

Product Filters

Size
(mm)		 Mounting
 Lumen
Output		 Light
Colour		 CRI
(Ra)		 Lm/W UGR
Rating		 Driver
Type		 Body
Colour
Image Part Code
Article Number		 Size
(mm)		 Mounting
 Lumen
Output		 Light
Colour		 CRI
(Ra)		 Lm/W
 UGR
Rating		 Driver
Type		 Body
Colour		 Data LDT Polar BIM
Product ImageROBUST DAWS840B2000
0637896		415 mmwide beam19520 lm4000 K≥ 80156,2 lm/W≤ 22DALI-2WhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST DAWS840B3000
0637898		415 mmwide beam30210 lm4000 K≥ 80154,9 lm/W≤ 25DALI-2WhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST DAWS840T2000
0637897		415 mmNarrow-beam19040 lm4000 K≥ 80152,3 lm/W≤ 16DALI-2WhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST DAWS840T3000
0637899		415 mmNarrow-beam28840 lm4000 K≥ 80147,9 lm/W≤ 16DALI-2WhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST DAWS865B2000
0637900		415 mmwide beam19520 lm6500 K≥ 80156,2 lm/W≤ 22DALI-2WhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST DAWS865B3000
0637902		415 mmwide beam30210 lm6500 K≥ 80154,9 lm/W≤ 25DALI-2WhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST DAWS865T2000
0637901		415 mmNarrow-beam19040 lm6500 K≥ 80152,3 lm/W≤ 16DALI-2WhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST DAWS865T3000
0637903		415 mmNarrow-beam28840 lm6500 K≥ 80147,9 lm/W≤ 16DALI-2WhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST NDWS840B2000
0627896		415 mmwide beam19520 lm4000 K≥ 80156,2 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST NDWS840B3000
0627898		415 mmwide beam30210 lm4000 K≥ 80154,9 lm/W≤ 25On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST NDWS840T2000
0627897		415 mmNarrow-beam19040 lm4000 K≥ 80152,3 lm/W≤ 16On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST NDWS840T3000
0627899		415 mmNarrow-beam28840 lm4000 K≥ 80147,9 lm/W≤ 16On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST NDWS865B2000
0627900		415 mmwide beam19520 lm6500 K≥ 80156,2 lm/W≤ 22On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST NDWS865B3000
0627902		415 mmwide beam30210 lm6500 K≥ 80154,9 lm/W≤ 25On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST NDWS865T2000
0627901		415 mmNarrow-beam19040 lm6500 K≥ 80152,3 lm/W≤ 16On/OffWhitePDFEulumdatProduct ImageEulumdat
Product ImageROBUST NDWS865T3000
0627903		415 mmNarrow-beam28840 lm6500 K≥ 80147,9 lm/W≤ 16On/OffWhitePDFEulumdatProduct ImageEulumdat

Technical Information

ROBUST

Compact and sturdy high output luminaire for suspending or surface mounting with a broad, narrow or diffuse distribution

Dimensions:
425 x 414 x H131mm
Output (lm):
15,000lm 23,000lm
Distribution:
Broad Beam
Control:
Non-Dimming, DALI

Colour Temperatures:
4,000K 6,500K
Colours:
Grey
IP Rating:
IP66

Specific Product Information and Downloads

ROBUST .. B - Broad Distribution
Product Code L
mm		 W
mm		 H
mm		 CCT Delivered
Lumens		 Power
W		 Data
Sheet		 Photometric
Data		 Product
ROBUST 15000-840 B / 0650575 425 mm 414 mm 131 mm 840 15630 lm 113 W PDF LDT IMG
ROBUST 15000-840 B-DA / 0660575 425 mm 414 mm 131 mm 840 15630 lm 113 W PDF LDT IMG
ROBUST 15000-865 B / 0650639 425 mm 414 mm 131 mm 865 15630 lm 113 W PDF LDT IMG
ROBUST 15000-865 B-DA / 0660639 425 mm 414 mm 131 mm 865 15630 lm 113 W PDF LDT IMG
ROBUST 23000-840 B / 0650576 425 mm 414 mm 131 mm 840 23450 lm 170 W PDF LDT IMG
ROBUST 23000-840 B-DA / 0660576 425 mm 414 mm 131 mm 840 23450 lm 170 W PDF LDT IMG
ROBUST 23000-865 B / 0650634 425 mm 414 mm 131 mm 865 23450 lm 170 W PDF LDT IMG
ROBUST 23000-865 B-DA / 0660634 425 mm 414 mm 131 mm 865 23450 lm 170 W PDF LDT IMG
ROBUST .. T - Narrow Distribution
Product Code L
mm		 W
mm		 H
mm		 CCT Delivered
Lumens		 Power
W		 Data
Sheet		 Photometric
Data		 Product
ROBUST 15000-840 T / 0650577 425 mm 414 mm 131 mm 840 15800 lm 113 W PDF LDT IMG
ROBUST 15000-840 T-DA / 0660577 425 mm 414 mm 131 mm 840 15800 lm 113 W PDF LDT IMG
ROBUST 15000-865 T / 0650648 425 mm 414 mm 131 mm 865 15800 lm 113 W PDF LDT IMG
ROBUST 15000-865 T-DA / 0660648 425 mm 414 mm 131 mm 865 15800 lm 113 W PDF LDT IMG
ROBUST 23000-840 T / 0650578 425 mm 414 mm 131 mm 840 23700 lm 170 W PDF LDT IMG
ROBUST 23000-840 T-DA / 0660578 425 mm 414 mm 131 mm 840 23700 lm 170 W PDF LDT IMG
ROBUST 23000-865 T / 0650649 425 mm 414 mm 131 mm 865 23700 lm 170 W PDF LDT IMG
ROBUST 23000-865 T-DA / 0660649 425 mm 414 mm 131 mm 865 23700 lm 170 W PDF LDT IMG
ROBUST .. OV - Diffuse Distribution
Product Code L
mm		 W
mm		 H
mm		 CCT Delivered
Lumens		 Power
W		 Data
Sheet		 Photometric
Data		 Product
ROBUST 15000-840 OV / 0650644 425 mm 414 mm 131 mm 840 15250 lm 113 W PDF LDT IMG
ROBUST 15000-840 OV-DA / 0660644 425 mm 414 mm 131 mm 840 15250 lm 113 W PDF LDT IMG
ROBUST 15000-865 OV / 0650645 425 mm 414 mm 131 mm 865 15250 lm 113 W PDF LDT IMG
ROBUST 15000-865 OV-DA / 0660645 425 mm 414 mm 131 mm 865 15250 lm 113 W PDF LDT IMG
ROBUST 23000-840 OV / 0650646 425 mm 414 mm 131 mm 840 22870 lm 170 W PDF LDT IMG
ROBUST 23000-840 OV-DA / 0660646 425 mm 414 mm 131 mm 840 22870 lm 170 W PDF LDT IMG
ROBUST 23000-865 OV / 0650647 425 mm 414 mm 131 mm 865 22870 lm 170 W PDF LDT IMG
ROBUST 23000-865 OV-DA / 0660647 425 mm 414 mm 131 mm 865 22870 lm 170 W PDF LDT IMG
