H80-Profil

DESIGN EXCELLENCE IN EVERY SHAPE AND COLOUR

The IF Award winning Spectral H Profil is a design classic. The underlying basis for the simple design is the characteristic H Profiled ‘track’ which can be suspended to any length and finished in any colour and comes in every conceivable shape. It offers an inherent strength and flexibility for creative and individual designs.

INSPIRING INDIVIDUALISM

Many light inserts are available to mount to the H Profil track. Creativity holds no bounds with the ability to specify modern or historic elements to suit the space. The number you choose are down to you. Add to this easily components are easily accessible for simple installation and inspection. Once you have designed the structure you require, H80 profile system is supplied completely assembled in dedicated wooden crates.

NO HOLDS BARRED

A toolbox of options, with H80 profile we have a solution for every area. Directional spotlights fixed high performing down lights or homogeneous linear lighting; the options are endless. See the video. We are open to ideas

BEND THE RULES

With a nod to the 19th century Gasoliers which had gas lights ornately hung off pendant structures, H Profil ‘chandeliers‘ can be supplied in many bespoke diameters and have been installed throughout the world. But such is the flexibility of the H Profil system that linear luminaires for workplaces can also be produced – tailor-made solutions are the H Profil’s function. Bend the rules.

Technical Information

H80-Profil Modules

Modules for use in Straight Profiles
Product Image Name Article Number Datasheet Photometric Data
H80 BLINDABDECKUNG 100 SW Art.-Nr. SPN0000085AQ PDF
H80 BLINDABDECKUNG 100 SI Art.-Nr. SPN0000085SI PDF
H80 STS 100 DA-SW Art.-Nr. SPN0000084AQ PDF
H80 STS 100 DA-SI Art.-Nr. SPN0000084SI PDF
H80 ALUZYL 1800-830 F-DA-SW Art.-Nr. SPN0000054AQ PDF LDT
H80 ALUZYL 1800-830 F-DA-SI Art.-Nr. SPN0000054SI PDF LDT
H80 ALUZYL 1800-840 F-DA-SW Art.-Nr. SPN0000055AQ PDF LDT
H80 ALUZYL 1800-840 F-DA-SI Art.-Nr. SPN0000055SI PDF LDT
H80 ALUZYL 1800-830 M-DA-SW Art.-Nr. SPN0000100AQ PDF LDT
H80 ALUZYL 1800-830 M-DA-SI Art.-Nr. SPN0000100SI PDF LDT
H80 ALUZYL 1800-840 M-DA-SW Art.-Nr. SPN0000101AQ PDF LDT
H80 ALUZYL 1800-840 M-DA-SI Art.-Nr. SPN0000101SI PDF LDT
H80 ALUZYL 1800-830 S-DA-SW Art.-Nr. SPN0000102AQ PDF LDT
H80 ALUZYL 1800-830 S-DA-SI Art.-Nr. SPN0000102SI PDF LDT
H80 ALUZYL 1800-840 S-DA-SW Art.-Nr. SPN0000103AQ PDF LDT
H80 ALUZYL 1800-840 S-DA-SI Art.-Nr. SPN0000103SI PDF LDT
H80 CURA-55 1750-830 F-DA-FSW Art.-Nr. SPN0000116AQ PDF LDT
H80 CURA-55 1750-830 F-DA-SI Art.-Nr. SPN0000116SI PDF LDT
H80 CURA-55 1800-840 F-DA-FSW Art.-Nr. SPN0000117AQ PDF LDT
H80 CURA-55 1800-840 F-DA-SI Art.-Nr. SPN0000117SI PDF LDT
H80 CURA-55 1750-830 M-DA-FSW Art.-Nr. SPN0000114AQ PDF LDT
H80 CURA-55 1750-830 M-DA-SI Art.-Nr. SPN0000114SI PDF LDT
H80 CURA-55 1800-840 M-DA-FSW Art.-Nr. SPN0000115AQ PDF LDT
H80 CURA-55 1800-840 M-DA-SI Art.-Nr. SPN0000115SI PDF LDT
H80 CURA-55 1750-830 S-DA-FSW Art.-Nr. SPN0000112AQ PDF LDT
H80 CURA-55 1750-830 S-DA-SI Art.-Nr. SPN0000112SI PDF LDT
H80 CURA-55 1800-840 S-DA-FSW Art.-Nr. SPN0000113AQ PDF LDT
H80 CURA-55 1800-840 S-DA-SI Art.-Nr. SPN0000113SI PDF LDT
H80 GLASLI. 1800-830 F-DA-SW Art.-Nr. SPN0000058AQ PDF LDT
H80 GLASLI. 1800-830 F-DA-SI Art.-Nr. SPN0000058SI PDF LDT
H80 GLASLI. 1800-840 F-DA-SW Art.-Nr. SPN0000059AQ PDF LDT
H80 GLASLI. 1800-840 F-DA-SI Art.-Nr. SPN0000059SI PDF LDT
H80 GLASLI. 1700-TW F-DA-SW Art.-Nr. SPN0000095AQ PDF LDT
H80 GLASLI. 1700-TW F-DA-SI Art.-Nr. SPN0000095SI PDF LDT
H80 GLASZYL 1800-830 DA-SW Art.-Nr. SPN0000060AQ PDF LDT
H80 GLASZYL 1800-830 DA-SI Art.-Nr. SPN0000060SI PDF LDT
H80 GLASZYL 1800-840 DA-SW Art.-Nr. SPN0000061AQ PDF LDT
H80 GLASZYL 1800-840 DA-SI Art.-Nr. SPN0000061SI PDF LDT
H80 GLASZYL 1700-TW-DA-SW Art.-Nr. SPN0000097AQ PDF LDT
H80 GLASZYL 1700-TW-DA-SI Art.-Nr. SPN0000097SI PDF LDT
H80 IND FLAT154 DASW-380B830 Art.-Nr. SPN0000082AQ PDF LDT
H80 IND FLAT154 DASI-380B830 Art.-Nr. SPN0000082SI PDF LDT
H80 IND FLAT154 DASW-380B840 Art.-Nr. SPN0000083AQ PDF LDT
H80 IND FLAT154 DASI-380B840 Art.-Nr. SPN0000083SI PDF LDT
H80 IND PUNKT 1800-830 DA-SW Art.-Nr. SPN0000066AQ PDF LDT
H80 IND PUNKT 1800-830 DA-SI Art.-Nr. SPN0000066SI PDF LDT
H80 IND PUNKT 1800-840 DA-SW Art.-Nr. SPN0000067AQ PDF LDT
H80 IND PUNKT 1800-840 DA-SI Art.-Nr. SPN0000067SI PDF LDT
H80 IND PUNKT 1700-TW-DA-SW Art.-Nr. SPN0000099AQ PDF LDT
H80 IND PUNKT 1700-TW-DA-SI Art.-Nr. SPN0000099SI PDF LDT
H80 LINE 115DASW-400DPO830 Art.-Nr. SPN0000074AQ PDF LDT
H80 LINE 115DASI-400DPO830 Art.-Nr. SPN0000074SI PDF LDT
H80 LINE 115DASW-400DPO840 Art.-Nr. SPN0000075AQ PDF LDT
H80 LINE 115DASI-400DPO840 Art.-Nr. SPN0000075SI PDF LDT
H80 LINE 115DASW-400MPS830 Art.-Nr. SPN0000070AQ PDF LDT
H80 LINE 115DASI-400MPS830 Art.-Nr. SPN0000070SI PDF LDT
H80 LINE 115DASW-400MPS840 Art.-Nr. SPN0000071AQ PDF LDT
H80 LINE 115DASI-400MPS840 Art.-Nr. SPN0000071SI PDF LDT
H80 LINE 115DASW-400OS830 Art.-Nr. SPN0000072AQ PDF LDT
H80 LINE 115DASI-400OS830 Art.-Nr. SPN0000072SI PDF LDT
H80 LINE 115DASW-400OS840 Art.-Nr. SPN0000073AQ PDF LDT
H80 LINE 115DASI-400OS840 Art.-Nr. SPN0000073SI PDF LDT
H80 LINE 115DASW-400ZB830 Art.-Nr. SPN0000076AQ PDF LDT
H80 LINE 115DASI-400ZB830 Art.-Nr. SPN0000076SI PDF LDT
H80 LINE 115DASW-400ZB840 Art.-Nr. SPN0000077AQ PDF LDT
H80 LINE 115DASI-400ZB840 Art.-Nr. SPN0000077SI PDF LDT
H80 LINE 115DASW-400ZEB830 Art.-Nr. SPN0000078AQ PDF LDT
H80 LINE 115DASI-400ZEB830 Art.-Nr. SPN0000078SI PDF LDT
H80 LINE 115DASW-400ZEB840 Art.-Nr. SPN0000079AQ PDF LDT
H80 LINE 115DASI-400ZEB840 Art.-Nr. SPN0000079SI PDF LDT
H80 MIREFA 020DASW-1350-830 Art.-Nr. SPN0000080AQ PDF LDT
H80 MIREFA 020DASI-1350-830 Art.-Nr. SPN0000080SI PDF LDT
H80 MIREFA 020DASW-1350-840 Art.-Nr. SPN0000081AQ PDF LDT
H80 MIREFA 020DASI-1350-840 Art.-Nr. SPN0000081SI PDF LDT
H80 ORTO 1260-830 DA-SW Art.-Nr. SPN0000068AQ PDF LDT
H80 ORTO 1260-830 DA-SI Art.-Nr. SPN0000068SI PDF LDT
H80 ORTO 1260-840 DA-SW Art.-Nr. SPN0000069AQ PDF LDT
H80 ORTO 1260-840 DA-SI Art.-Nr. SPN0000069SI PDF LDT
H80 PERGWÜRFEL 1800-830 DA-SW Art.-Nr. SPN0000064AQ PDF LDT
H80 PERGWÜRFEL 1800-830 DA-SI Art.-Nr. SPN0000064SI PDF LDT
H80 PERGWÜRFEL 1800-840 DA-SW Art.-Nr. SPN0000065AQ PDF LDT
H80 PERGWÜRFEL 1800-840 DA-SI Art.-Nr. SPN0000065SI PDF LDT
H80 PERGWÜRFEL 1700-TW-DA-SW Art.-Nr. SPN0000098AQ PDF LDT
H80 PERGWÜRFEL 1700-TW-DA-SI Art.-Nr. SPN0000098SI PDF LDT
H80 PERGAZYL 1800-830 DA-SW Art.-Nr. SPN0000062AQ PDF LDT
H80 PERGAZYL 1800-830 DA-SI Art.-Nr. SPN0000062SI PDF LDT
H80 PERGAZYL 1800-840 DA-SW Art.-Nr. SPN0000063AQ PDF LDT
H80 PERGAZYL 1800-840 DA-SI Art.-Nr. SPN0000063SI PDF LDT
H80 PERGAZYL 1700-TW-DA-SW Art.-Nr. SPN0000096AQ PDF LDT
H80 PERGAZYL 1700-TW-DA-SI Art.-Nr. SPN0000096SI PDF LDT
Modules for use in Curved Profiles
Product Image Name Article Number Datasheet Photometric Data
H80 ALUZYL 1800-830 F-DA-SW SPN0000054AQ PDF LDT
H80 ALUZYL 1800-830 F-DA-SI SPN0000054SI PDF LDT
H80 ALUZYL 1800-840 F-DA-SW SPN0000055AQ PDF LDT
H80 ALUZYL 1800-840 F-DA-SI SPN0000055SI PDF LDT
H80 ALUZYL 1800-830 M-DA-SW SPN0000100AQ PDF LDT
H80 ALUZYL 1800-830 M-DA-SI SPN0000100SI PDF LDT
H80 ALUZYL 1800-840 M-DA-SW SPN0000101AQ PDF LDT
H80 ALUZYL 1800-840 M-DA-SI SPN0000101SI PDF LDT
H80 ALUZYL 1800-830 S-DA-SW SPN0000102AQ PDF LDT
H80 ALUZYL 1800-830 S-DA-SI SPN0000102SI PDF LDT
H80 ALUZYL 1800-840 S-DA-SW SPN0000103AQ PDF LDT
H80 ALUZYL 1800-840 S-DA-SI SPN0000103SI PDF LDT
H80 CURA-55 1750-830 F-DA-FSW SPN0000116AQ PDF LDT
H80 CURA-55 1750-830 F-DA-SI SPN0000116SI PDF LDT
H80 CURA-55 1800-840 F-DA-FSW SPN0000117AQ PDF LDT
H80 CURA-55 1800-840 F-DA-SI SPN0000117SI PDF LDT
H80 CURA-55 1750-830 M-DA-FSW SPN0000114AQ PDF LDT
H80 CURA-55 1750-830 M-DA-SI SPN0000114SI PDF LDT
H80 CURA-55 1800-840 M-DA-FSW SPN0000115AQ PDF LDT
H80 CURA-55 1800-840 M-DA-SI SPN0000115SI PDF LDT
H80 CURA-55 1750-830 S-DA-FSW SPN0000112AQ PDF LDT
H80 CURA-55 1750-830 S-DA-SI SPN0000112SI PDF LDT
H80 CURA-55 1800-840 S-DA-FSW SPN0000113AQ PDF LDT
H80 CURA-55 1800-840 S-DA-SI SPN0000113SI PDF LDT
H80 GLASLI. 1800-830 F-DA-SW SPN0000058AQ PDF LDT
H80 GLASLI. 1800-830 F-DA-SI SPN0000058SI PDF LDT
H80 GLASLI. 1800-840 F-DA-SW SPN0000059AQ PDF LDT
H80 GLASLI. 1800-840 F-DA-SI SPN0000059SI PDF LDT
H80 GLASLI. 1700-TW F-DA-SW SPN0000095AQ PDF LDT
H80 GLASLI. 1700-TW F-DA-SI SPN0000095SI PDF LDT
H80 GLASZYL 1800-830 DA-SW SPN0000060AQ PDF LDT
H80 GLASZYL 1800-830 DA-SI SPN0000060SI PDF LDT
H80 GLASZYL 1800-840 DA-SW SPN0000061AQ PDF LDT
H80 GLASZYL 1800-840 DA-SI SPN0000061SI PDF LDT
H80 GLASZYL 1700-TW-DA-SW SPN0000097AQ PDF LDT
H80 GLASZYL 1700-TW-DA-SI SPN0000097SI PDF LDT
H80 IND PUNKT 1800-830 DA-SW SPN0000066AQ PDF LDT
H80 IND PUNKT 1800-830 DA-SI SPN0000066SI PDF LDT
H80 IND PUNKT 1800-840 DA-SW SPN0000067AQ PDF LDT
H80 IND PUNKT 1800-840 DA-SI SPN0000067SI PDF LDT
H80 IND PUNKT 1700-TW-DA-SW SPN0000099AQ PDF LDT
H80 IND PUNKT 1700-TW-DA-SI SPN0000099SI PDF LDT
H80 PERGWÜRFEL 1800-830 DA-SW SPN0000064AQ PDF LDT
H80 PERGWÜRFEL 1800-830 DA-SI SPN0000064SI PDF LDT
H80 PERGWÜRFEL 1800-840 DA-SW SPN0000065AQ PDF LDT
H80 PERGWÜRFEL 1800-840 DA-SI SPN0000065SI PDF LDT
H80 PERGWÜRFEL 1700-TW-DA-SW SPN0000098AQ PDF LDT
H80 PERGWÜRFEL 1700-TW-DA-SI SPN0000098SI PDF LDT
H80 PERGAZYL 1800-830 DA-SW SPN0000062AQ PDF LDT
H80 PERGAZYL 1800-830 DA-SI SPN0000062SI PDF LDT
H80 PERGAZYL 1800-840 DA-SW SPN0000063AQ PDF LDT
H80 PERGAZYL 1800-840 DA-SI SPN0000063SI PDF LDT
H80 PERGAZYL 1700-TW-DA-SW SPN0000096AQ PDF LDT
H80 PERGAZYL 1700-TW-DA-SI SPN0000096SI PDF LDT

H80-Profil Standard Chandeliers

Dimensions:
Ø: 2,000mm, 2,500mm, 3,000mm
H: 84mm
Optics:
Aluzylinder, Glaslinse, PergamentWurfel, Glaszylinder
Output (lm):
11,720 – 28,260 lm
Control:
DALI

Colour Temperatures:
4,000K
3,000K & Tuneable White on request
Colours:
Silver, White, any RAL on request + Numerous special finishes available
IP Rating:
IP20

Specific Product Data - Aluzylinder Chandelier
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
H80-K-I-2000-ALUZYL-840-DA-SI 92 mm 2000 mm 840 17480 lm 162 W PDF LDT IMG
H80-K-I-2000-ALUZYL-840-DA-W 92 mm 2000 mm 840 17480 lm 162 W PDF LDT IMG
H80-K-I-2500-ALUZYL-840-DA-SI 92 mm 2500 mm 840 21850 lm 203 W PDF LDT IMG
H80-K-I-2500-ALUZYL-840-DA-W 92 mm 2500 mm 840 21850 lm 203 W PDF LDT IMG
H80-K-I-3000-ALUZYL-840-DA-SI 92 mm 3000 mm 840 26220 lm 243 W PDF LDT IMG
H80-K-I-3000-ALUZYL-840-DA-W 92 mm 3000 mm 840 26220 lm 243 W PDF LDT IMG
Specific Product Data - Glaslinse Chandelier
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
H80-K-I-2000-GLASLI-840-DA-SI 84 mm 2000 mm 840 18840 lm 162 W PDF LDT IMG
H80-K-I-2000-GLASLI-840-DA-W 84 mm 2000 mm 840 18840 lm 162 W PDF LDT IMG
H80-K-I-2500-GLASLI-840-DA-SI 84 mm 2500 mm 840 23550 lm 203 W PDF LDT IMG
H80-K-I-2500-GLASLI-840-DA-W 84 mm 2500 mm 840 23550 lm 203 W PDF LDT IMG
H80-K-I-3000-GLASLI-840-DA-SI 84 mm 3000 mm 840 28260 lm 243 W PDF LDT IMG
H80-K-I-3000-GLASLI-840-DA-W 84 mm 3000 mm 840 28260 lm 243 W PDF LDT IMG
Specific Product Data - Glaszylinder Chandelier
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
H80-K-I-2000-GLASZYL-840-DA-SI 176 mm 2000 mm 840 18840 lm 162 W PDF LDT IMG
H80-K-I-2000-GLASZYL-840-DA-W 176 mm 2000 mm 840 18840 lm 162 W PDF LDT IMG
H80-K-I-2500-GLASZYL-840-DA-SI 176 mm 2500 mm 840 23550 lm 203 W PDF LDT IMG
H80-K-I-2500-GLASZYL-840-DA-W 176 mm 2500 mm 840 23550 lm 203 W PDF LDT IMG
H80-K-I-3000-GLASZYL-840-DA-SI 176 mm 3000 mm 840 28260 lm 243 W PDF LDT IMG
H80-K-I-3000-GLASZYL-840-DA-W 176 mm 3000 mm 840 28260 lm 243 W PDF LDT IMG
Specific Product Data - PergamentWurfel Chandelier
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
H80-K-I-2000-PERGAWÜ-840-DA-SI 116 mm 2000 mm 840 11720 lm 162 W PDF LDT IMG
H80-K-I-2000-PERGAWÜ-840-DA-W 116 mm 2000 mm 840 11720 lm 162 W PDF LDT IMG
H80-K-I-2500-PERGAWÜ-840-DA-SI 116 mm 2500 mm 840 14650 lm 203 W PDF LDT IMG
H80-K-I-2500-PERGAWÜ-840-DA-W 116 mm 2500 mm 840 14650 lm 203 W PDF LDT IMG
H80-K-I-3000-PERGAWÜ-840-DA-SI 116 mm 3000 mm 840 17580 lm 243 W PDF LDT IMG
H80-K-I-3000-PERGAWÜ-840-DA-W 116 mm 3000 mm 840 17580 lm 243 W PDF LDT IMG
Specific Product Data - PergamentZylinder Chandelier
Product Code H
mm
Ø
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
H80-K-I-2000-PERGAZY-840-DA-SI 120 mm 2000 mm 840 12240 lm 162 W PDF LDT IMG
H80-K-I-2000-PERGAZY-840-DA-W 120 mm 2000 mm 840 12240 lm 162 W PDF LDT IMG
H80-K-I-2500-PERGAZY-840-DA-SI 120 mm 2500 mm 840 15300 lm 203 W PDF LDT IMG
H80-K-I-2500-PERGAZY-840-DA-W 120 mm 2500 mm 840 15300 lm 203 W PDF LDT IMG
H80-K-I-3000-PERGAZY-840-DA-SI 120 mm 3000 mm 840 18360 lm 243 W PDF LDT IMG
H80-K-I-3000-PERGAZY-840-DA-W 120 mm 3000 mm 840 18360 lm 243 W PDF LDT IMG

H80-Profil Standard Mirefa Luminaires

Dimensions:
L: 1500mm, W:80mm, H80mm
Optics:
Mirefa
Output (lm):
7,580 – 7,900 lm
Control:
DALI

Colour Temperatures:
4,000K
3,000K
Colours:
Black, White, Silver or any RAL on request + Numerous special finishes available
IP Rating:
IP20

Specific Product Data - H80 Mirefa Linear Luminaire
Product Code L
mm
W
mm
H
mm
CCT Delivered
Lumens
Power
W
Data
Sheet
Photometric
Data
Product
H80 MIREFA-DI 150DAFSW-770-830 1500 mm 80 mm 80 mm 830 7580 lm 60 W PDF LDT IMG
H80 MIREFA-DI 150DAFSW-800-840 1500 mm 80 mm 80 mm 840 7900 lm 60 W PDF LDT IMG
H80 MIREFA-DI 150DAFWS-770-830 1500 mm 80 mm 80 mm 830 7580 lm 60 W PDF LDT IMG
H80 MIREFA-DI 150DAFWS-800-840 1500 mm 80 mm 80 mm 840 7900 lm 60 W PDF LDT IMG
H80 MIREFA-DI 150DASI-770-830 1500 mm 80 mm 80 mm 830 7580 lm 60 W PDF LDT IMG
H80 MIREFA-DI 150DASI-800-840 1500 mm 80 mm 80 mm 840 7900 lm 60 W PDF LDT IMG

Download

H-Profil Brochure

Projects Featuring H80-Profil

Wolfson College Buttery

Wolfson College Buttery

Oxford UniversityWolfson College was founded in 1966 and is the largest and most international of the Oxford ...
Bristol Central Library

Bristol Central Library

Building services are changing and the way they are managed continues to evolve, even when the physical structure ...
Porsche Centre, Oslo

Porsche Centre, Oslo

Porsche and Spectral. The two Stuttgart based companies have worked in collaboration again, this time for Porsche ...
St Matthews Church, Cambridge

St Matthews Church, Cambridge

Built in 1866 and designed by Richard Rowe, one-time understudy to George Gilbert Scott in the 1850s in his work at Ely Cathedral.
1

Pin It on Pinterest

Share This
